Chapter 8 Print Unit
8.1 Description, cont.
Stepper Motor
Ribbon Assist Roller
Platen Roller
Printhead
Tear Bar
Liner Drive Roller
50
EasyCoder 601 XP
Intermec EasyCoder 501 XP & 601 XP – Service Manual
Belt to Ribbon Rewind Unit
Label Stop Sensor
(hidden)
Headlift Mechanism
Locking Handle
(in open position)
