Chapter 8 Print Unit
EasyCoder 501 XP
8.1 Description, cont.
Belt to Ribbon Rewind Unit
Stepper Motor
Headlift Mechanism
Ribbon Assist Roller
Platen Roller
Printhead
Tear Bar
Liner Drive Roller
Label Stop Sensor
