8.2 Platen Roller, cont.
Stepper Motor
#T20 Torx Screw
Belt to Platen Roller
Pulley
Ball Bearing
Plastic Bearing
Spacer
Platen Roller
Intermec EasyCoder 501 XP & 601 XP – Service Manual
EasyCoder 601 XP
In the illustration below, the upper parts of the print unit and the
label stop sensor have been omitted to improve visibility.
#T20 Torx Screw
Plastic Bearing
Ball Bearing
Chapter 8 Print Unit
Belt to Ribbon Rewind Unit
Bracket
#T20 Torx Screw (1)
55
