Chapter 1 Models and Options

1.5 EasyCoder 601 XP Measures

38 mm
(1.50")
135.4 mm (5.33")
68.8 mm
(2.71")
An optional paper cutter increases the printer's total length by 28 mm (1.1 inches).
At least 90 mm (3.5 inches) of free space behind the printer is required for the connectors,
18
259 mm (10.20")
168 mm (6.61")
335 mm (13.18")
Dot No. 0
and for inserting and removing a memory card.
238 mm
(9.37")
79 mm
(3.11")
363 mm (14.29")
481.5 mm (18.96")
Intermec EasyCoder 501 XP & 601 XP– Service Manual
20 mm
(0.79")
Paper slot
186 mm
(7.32")
20 mm
(0.79")
Paper slot
30 mm
(1.18")
12 mm
(0.47")
