Chapter 5 Media Supply
5.1 Internal Supply,
cont.
32
One or two adapters (standard accessories) can be fi tted onto the
media supply hub in order to accept media rolls with 76 mm (3
inches) cores. EasyCoder 501 XP has one adapter and EasyCoder
601 XP has two. Each adapter is locked using a #T20 Torx screw.
Be careful not to let the screw hit the leaf springs or the cams of the
hub modules.
3-inch Adapter
3-inch Adapters
EasyCoder 501 XP
EasyCoder 601 XP
