4 . 1 6 . 4 U S B D e v i c
4 . 1 6 . 4 U S B D e v i c
This page is to monitor the status for the users who accessing into FTP (USB storage disk) via
the Vigor router. In addition, the status of the USB printer connecting to Vigor router can be
checked from such page. If you want to remove the storage disk from USB port in router,
please click Disconnect USB Disk first. And then, remove the USB storage disk later.
Available settings are explained as follows:
Item
Connection Status
Disk Capacity
Free Capacity
Index
IP Address
Username
When you insert USB storage disk into the Vigor router, the system will start to find out such
device within several seconds.
e S t a t u s
e S t a t u s
Description
If there is no USB storage disk connected to Vigor router,
"No Disk Connected" will be shown here.
It displays the total capacity of the USB storage disk.
It displays the free space of the USB storage disk. Click
Refresh at any time to get new status for free capacity.
It displays the number of the client which connecting to
FTP server.
It displays the IP address of the user's host which
connecting to the FTP server.
It displays the username that user uses to login to the FTP
server.
373
Vigor2132 Series User's Guide
