3.7

Assembly overview - window regulator motor

Note
The right side is shown. The left side is similar.
1 - Connector
2 - Bolt
❑ Qty. 3
❑ 3.5 Nm
3 - Window regulator motor
❑ Removing and installing
⇒ page 302
3.8 Removing and installing window regula‐
tor motor
Note
The removal and installation sequence is only for the right window
regulator motor. The removal and installation of the left window
regulator motor is similar.
3.8.1 Removing
– Removing door trim ⇒ General body repairs, interior; Rep. Gr.
70 ; Door trim .
