"Connecting the server to the mains" on page 67
Ê
"Switching on the server" on page 68
Ê
"Updating RAID controller firmware" on page 80
Ê
Ê If applicable, "Enabling Option ROM scan" on page 81
"Enabling SVOM boot watchdog functionality" on page 84
Ê
"Enabling BitLocker functionality" on page 90
Ê
Ê If applicable, "After replacing / upgrading LAN controllers" on page 94
9.4.2

Removing expansion cards

Upgrade and Repair Unit
(URU)
Tools: tool-less
9.4.2.1

Preliminary steps

"Disabling BitLocker functionality" on page 69
Ê
"Shutting down the server" on page 46
Ê
"Disconnecting the server from the mains" on page 46
Ê
Ê Remove all external cables from the expansion card to be removed.
"Getting access to the component" on page 47
Ê
"Removing the fan module" on page 151
Ê
TX1330 M1
Upgrade and Maintenance Manual
Expansion cards and backup units
Hardware: 5 minutes
