8.2
Handling the fan module
Upgrade and Repair Unit
(URU)
Tools: tool-less
8.2.1
Preliminary steps
"Shutting down the server" on page 46
Ê
"Disconnecting the server from the mains" on page 46
Ê
"Getting access to the component" on page 47
Ê
8.2.2
Removing the fan module
Figure 69: Removing the fan module
Ê Disconnect the fan cable from system board connector "FAN1 SYS" (1).
TX1330 M1
Upgrade and Maintenance Manual
System fan and air duct
Hardware: 5 minutes
151
