14.4.3.2 Removing the defective TPM

Ê Remove the TPM as described in section
Ê Leave the TPM spacer on the system board when removing the defective
TPM.

14.4.3.3 Installing the new TPM

Ê The TPM spacer is already present on the system board.
Ê Install the TPM as described in section

14.4.3.4 Concluding steps

"Installing the fan module" on page 152
Ê
"Reassembling" on page 58
Ê
"Connecting the server to the mains" on page 67
Ê
"Switching on the server" on page 68
Ê
"Enabling BitLocker functionality" on page 90
Ê
TX1330 M1
Upgrade and Maintenance Manual
System board and components
"Removing the TPM" on page
"Installing the TPM" on page
268.
264.
273
