Ê Disconnect the power cord from the power supply unit and remove it from
the cable tie.
I
If you are using a redundant power supply with two power supply units,
proceed with the second power supply unit in the same way.
4.4

Getting access to the component

V
CAUTION!
Only valid for the tower model:
Don't lift the server by using the front cover. There is a possibility that the
HDD bay cover hook is broken.
V
CAUTION!
Before removing or installing covers, turn off the server and all
●
peripheral devices. Also unplug all power cables from the outlet.
Failure to do so can cause electric shock.
In order to comply with applicable EMC regulations (regulations on
●
electromagnetic compatibility) and satisfy cooling requirements, the
server must not run while the top / side cover is removed.
For further safety information, please refer to chapter
●
information" on page
4.4.1

Rack model

4.4.1.1

Extending the server out of the rack

V
CAUTION!
Use the anti-tilt plate to prevent the rack from tipping when installing
●
the rack. Pulling the server out of the rack without having installed the
anti-tilt plate may cause the rack to tip over.
Be careful not to pinch fingers or clothes when sliding out the server
●
or pushing it back. Failure to do so may cause injury.
For further safety information, please refer to chapter
●
information" on page
TX1330 M1
31.
31.
Upgrade and Maintenance Manual
Basic hardware procedures
"Important
"Important
47
