Configuring the Data Link Layer Protocol for E1, T1, and Serial Interfaces
Configuring the Logical Interface
N o t e
N o t e
6-36
For example, if you want to bind the E1 1/1 interface to the Frame Relay 1
interface, enter:
ProCurve(config)# bind 1 e1 1/1 1 fr 1
You bind the physical interface to the Frame Relay interface (not to the
subinterface).
If you want to bind the serial 1/1 interface to the Frame Relay 1 interface, enter:
ProCurve(config)# bind 1 ser 1/1 fr 1
When you bind a serial interface to the Frame Relay interface, you do not
include a TDM group number because the serial interface does not use TDM
groups.
To see an example configuration that uses Frame Relay, see "Example Net-
works" on page 6-46.

Additional Settings

Depending on your company's WAN environment, you may want to configure
other options on the Frame Relay interface or subinterface.
Configure a Secondary IP Address for the Subinterface. You can con-
figure a secondary IP address on the Frame Relay subinterface. Enter:
Syntax: ip address <A.B.C.D> <subnet mask | /prefix length> secondary
Replace <A.B.C.D> with secondary IP address and specify a subnet mask
using the <subnet mask> option or the </prefix length> option. Finally,
include the secondary option.
For example, you might enter:
ProCurve(config-fr 1.1)# ip address 192.168.115.1 255.255.255.252 secondary
To remove the secondary IP address, enter:
Syntax: no ip address <A.B.C.D> <subnet mask | /prefix length> secondary
You can include an unlimited number of secondary IP addresses.
