Motorized Shutter Connector
There are two connectors for connecting the motorized shutter cable: "EPI SHUTTER" on the rear of the main body and
"DIA SHUTTER" on the connector box. Connect the EPI motorized shutter on the epi-fluorescence side to the "EPI
SHUTTER" connector and the DIA motorized shutter on the dia-illumination side to the "DIA SHUTTER" connector.
These are set by factory default. Change the setting if you intend to use the motorized shutter for AUX (other than
EPI/DIA).
Change the configuration on the DS-L3. (See "20 Operation on DS-L3" - "20.1 Setting Up the Microscope - (2)
Configuring the Device Connection Information" for details.)
■ Motorized HG precentered fiber illuminator
Press the FL SHUTTER button to open/close the motorized HG precentered fiber illuminator. Change the FL
SHUTTER button function to the opening/closing operation function of the motorized HG precentered fiber illuminator.
"The shutter is closed" when the button is ON.
Change the FL SHUTTER button function on the DS-L3. (See "20 Operation on DS-L3" - "20.1 Setting Up the
Microscope - (3-1) Ni-E microscope button" for details.)
Grouped operation of EPI side shutters
Three types of shutters on the EPI side (including the
shutter in the epi-fluorescence cube turret in the 2nd layer,
if attached) can be opened and closed all at once. This is
performed with the ergo controller's EPI all switch. See
the Ni-E (Focusing Stage System) instruction manual for
details of the ergo controller.
Grouped operation of EPI side shutters is not available in
sleep mode. A message showing "Sleep mode is active.
Drive/operation not available" is displayed and you hear a
buzz. (Beep) The warning disappears automatically
approximately after 3 seconds. Reset the sleep mode
before you continue the operation.
(See "20 Operation on DS-L3" - "20.1 Setting Up the
Microscope - (3-3) Buttons on the Screens on DS-L3 - ■
SLEEP button" for details.)
Operation on DS-L3 (See "20.2 Microscope Control".)
Intelligent/manual epi-fluorescence cube turret shutter
See the Ni-E (Focusing Stage System) instruction manual for details on the intelligent/manual epi-fluorescence cube
turret shutter operation.
Chapter 3
Individual Operations
While in sleep mode, drive operation of motorized
74
P A _ _ 2 * _ S L E E P _ M O D E _
[ E R 2 ] D e v i c e _ U n a v a i l a b l e .
units not available
*
