N o t e
N o t e
Configuring the Data Link Layer Protocol for E1, T1, and Serial Interfaces
Replace <physical interface> with E1, T1, or serial. The <slot> and <port>
pinpoint this interface's location on the ProCurve Secure Router and distin-
guish multiple lines of the same type from each other.
If you are binding the Frame Relay interface to an E1 or T1 interface, replace
<tdm-group number> with the TDM group you created when you configured
that interface. If you are binding the serial interface to the Frame Relay
interface, you do not include this option.
In this instance, the <logical interface> is Frame Relay, and the <logical
interface number> refers to the number you assigned to this interface.
For example, if you want to bind the E1 1/1 interface to the Frame Relay 1
interface, enter:
ProCurve(config)# bind 1 e1 1/1 1 fr 1
You bind the physical interface to the Frame Relay interface (not to the
subinterface).
If you want to bind the serial 1/1 interface to the Frame Relay 1 interface, enter:
ProCurve(config)# bind 1 ser 1/1 fr 1
When you bind a serial interface to the Frame Relay interface, you do not
include a TDM group number because the serial interface does not use TDM
groups.
To see an example configuration that uses Frame Relay, see "Example Net-
works" on page 6-48.

Additional Settings

Depending on your company's WAN environment, you may want to configure
other options on the Frame Relay interface or subinterface.
Configure a Secondary IP Address for the Subinterface. You can con-
figure a secondary IP address on the Frame Relay subinterface. Enter:
Syntax: ip address <A.B.C.D> <subnet mask | /prefix length> secondary
Replace <A.B.C.D> with secondary IP address and specify a subnet mask
using the <subnet mask> option or the </prefix length> option. Finally,
include the secondary option.
Configuring the Logical Interface
6-37
