I Microphone [F-1]/[F-2] keys
Switches on the transceiver's front panel can be assigned to
the microphone's [F-1] and [F-2] keys.
➀
Turn power OFF.
➁
While pushing the desired switch on the transceiver and
[F-1] or [F-2] on the microphone, turn power ON.
• The switches' function is programmed into the key ([F-1] or [F-2]).
• Default setting
The following functions are assigned to the [F-1]/[F-2] keys
when first applying power or after CPU resetting:
[F-1]: VHF band tuning dial switch
[F-2]: UHF band tuning dial switch
I Display dimmer setting
Adjust the intensity intensity to suit lighting conditions and
personal preference.
➀
Push and hold [
D] (right side) until "d-1"–"d4" ap-
VOL(SET)
pears as shown below.
9
OTHER FUNCTIONS
➁
Rotate the tuning dial (right side) to set the desired inten-
sity.
• Intensity can be set from "d1" (dark) to "d4" (bright).
➂
Push [
D] to return to normal operation.
VOL(SET)
I Demonstration display
A demonstration function is available at power ON. This func-
tion gives you a quick visual introduction to the function dis-
play indicators.
➀
While pushing either tuning dial, push [POWER] to turn
power ON.
• The transceiver cycles through a visual tour of the function dis-
play indicators.
➁
Push any switch to exit demonstration mode and enter the
normal operating condition temporarily.
NOTE: The transceiver automatically returns to demon-
stration mode after 2 min. in which no operations are per-
formed. To deactivate the demonstration display
permanently, perform step ➀ again.
