- Page 1 INSTRUCTION MANUAL DUAL BAND TRANSCEIVER i2730A i2730E...
- Page 2 • Force majeure, including, but not limited to, fires, earthquakes, Spare fuse Microphone storms, floods, lightning, other natural disasters, disturbances, (FGB 15 A) hanger riots, war, or radioactive contamination. • The use of Icom transceivers with any equipment that is not manufactured or approved by Icom.
- Page 3 If you experi- smoke. Contact your Icom dealer or distributor for advice. ence ringing, reduce the volume level or discontinue use.
- Page 4 Use Icom microphones only (supplied or optional). Other manu- DO NOT use or place the transceiver in areas with tempera- facturer’s microphones have different pin assignments, and may tures below –10°C (+14°F) or above +60°C (+140°F).
- Page 5 TABLE OF CONTENTS INSTALLATION AND CONNECTIONS 63 EXPLICIT DEFINITIONS ....... i ■ Writing into a Memory or Call IMPORTANT ..........i channel ..........30 ■ Connecting to a DC power supply ... 64 SUPPLIED ACCESSORIES ......i ■ Setting a Memory bank ....32 ■...
- Page 6 PANEL DESCRIPTION ■ Controller — Front panel e VFO/MHz TUNING•SCAN KEY [V/MHz SCAN] Microphone ➥ Push to select the VFO mode. Display (p. 2) connector (pp. 5, 63) ➥ In the VFO mode, push to select 1 MHz tuning. (p. 24) ➥...
- Page 7 PANEL DESCRIPTION ■ Controller — Display i MONITOR•DUPLEX KEY [DUP MONI] ➥ Push to turn the Monitor function ON and OFF. (p. 27) q w e ➥ Hold down for 1 second to display the duplex direction setting screen. (p. 50) o OUTPUT POWER•DTMF KEY [LOW DTMF] ➥...
- Page 8 PANEL DESCRIPTION ■ Controller — Display (Continued) !3 VOX ICON (p. 75) Displayed when the transceiver is connected to the option- al VS-3 , and the VOX function is ON. ® Bluetooth headset !4 MEMORY MODE ICON (p. 29) Displayed while in the Memory mode. !5 S/RF METER ➥...
- Page 9 PANEL DESCRIPTION !8 ENTER KEY [ï] Push to go to the next tree level or to set the option or value in the MENU mode. (pp. 11, 30) !9 LEFT/RIGHT KEYS [Ω]/[≈] In the MENU mode (p. 11) [Ω]: Push to go back the previous tree level. [≈]: Push to go to the next tree level.
- Page 10 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ A-7194H-1Ex-e Printed in Japan 2014–2017 Icom Inc. © 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
