16
WIRELESS OPERATION
I Microphone
address
The transceiver has 8 possible microphone addresses to help
prevent interference from other HM-90
. Set both the microphone address and microphone
PHONES
dip switch to the same value as follows.
NOTE: When the supplied microphone is connected, the
transceiver rejects control signals from the HM-90 even
when the microphone address is matched.
D Microphone address
➀
Push [POWER] to turn power
OFF.
➁
While pushing [
turn power ON to enter initial
set mode.
➂
Push [SET] a few times to se-
lect the "Adr" display as
shown at right.
➃
Rotate the left-hand tuning dial to set the microphone ad-
dress to 0–7 or to turn the microphone control OFF.
• When "Adr-oF" is selected, the transceiver rejects all control sig-
nals from the HM-90.
➄
Turn power OFF to exit initial set mode.
71
INITIAL SET MODE
USING
WIRELESS MICRO
SET L],
(VOL)
The display shows the mi-
crophone address is set to 1.
D Microphone dip switch
➀
Remove the switch cover from the microphone rear panel.
➁
Set the microphone dip switch and the microphone ad-
dress to the same value as shown below.
-
➂
Replace the switch cover.
MICROPHONE
ADDRESS
Adr-0
Adr-1 (default)
Adr-2
Adr-3
Adr-4
Adr-5
Adr-6
Adr-7
(S1)
Dip switch
ON
1 2 3
OFF
DIP SWITCH
S1–1
S1–2
S1–3
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
OFF
OFF
ON
ON
OFF
ON
OFF
ON
ON
ON
ON
ON
Switch cover
LOCK
AFC
AFC-OFF
PTT-M
MW
CALL
MR
VFO
CLR
1
2
3
A
PGR
C-SQL
DTMF
D-OFF
HIGH
MID
LOW
SET
4
5
6
B
