4
BASIC OPERATION

I Transmitting

CAUTION:
Transmitting without an antenna may dam-
age the transceiver.
NOTE:
➥ To prevent interference, listen on the frequency before
transmitting by pushing the main band's [
the microphone's [➀MONI].
➥ To prevent howling and sensitivity rejection, AVOID set-
ting the 430(440) MHz band frequency near a multiple
of the 144 MHz band frequency, e.g. setting for
145 MHz and 435 MHz.
➀
Push the desired band's tuning dial to select the main band
for transmitting.
➁
Set the operating frequency. (pgs. 15–19)
• Select output power if desired. See section at right for details.
➂
Push and hold [PTT] to transmit.
• "$" appears.
• The S/RF indicator shows the output power selection.
• The operating frequency, etc. are automatically programmed into
a scratch pad memory. See p. 39 for details.
• One-touch PTT function is available. See p. 26 for details.
25
➃
Speak into the microphone using your normal voice level.
• DO NOT hold the microphone too close to your mouth or speak
too loudly. This may distort the signal.
➄
Release [PTT] to return to receive.

I Selecting the output power

MONI] or
(SQL)
The transceiver has 3 output power levels to suit your oper-
ating requirements. Lower output power during short-distance
communication may reduce interference to other stations and
reduces current consumption.
➀
Push the desired band's tuning dial.
➁
Push [LOW] one or more times to select the desired out-
put power.
• The output power can be changed while transmitting.
POWER
SELECTION
HIGH
MID
LOW
S/RF INDICATOR
VHF
50 W
1 5 9
10 W
LOW
1 1 5 5
5 W
LOW
1 1
UHF
35 W
10 W
5 W
