Specifications - Icom IC-2710H Instruction Manual

General
• Frequency coverage
VERSION
Tx 144–148 MHz
U.S.A.
Rx
118–174 MHz*
Tx 144–148 MHz
Asia
Rx
136–174 MHz*
Europe 144–146 MHz
Tx 144–146 MHz
Italy
Rx
136–174 MHz*
1
* 118–136 MHz is usable in the VHF display only; guaranteed frequency cov-
erage is 144–148 MHz.
2
* Guaranteed frequency coverage is 144–148 MHz.
3
* Guaranteed frequency coverage is 430–440 MHz.
• Mode
• Antenna impedance
• Power supply requirement
• Usable temperature range
• Dimensions
(projections not included)
• Weight
Transmitter
• Modulation system
• Max. frequency deviation
• Spurious emissions
• Microphone impedance
VHF UHF
440–450 MHz
1
430–440 MHz
2
430–440 MHz
430–440 MHz
2
400–479 MHz*
: FM, AM*
(*U.S.A. version only; 118–136 MHz)
: 50 Ω
)
(SO-239
: 13.8 V DC ± 15%
: –10°C to +60°C; +14°F to +140°F
: 140(W) x 40(H) x 212.4(D) mm
1 9 3
5 ⁄ (W) x 1 ⁄ (H) x 8 ⁄ (D) in
2 16 8
: 1.4 kg; 3.1 lb
: Variable reactance frequency
modulation
: ± 5.0 kHz
: Less than –60 dB
: 600 Ω
(8-pin modular)

SPECIFICATIONS

• Output power and current drain:
CONDITION
144 MHz
430(440) MHz
3 Receiver
• Receive system
• Intermediate frequencies
Left display band
Right display band
• Sensitivity
(for 12 dB SINAD)
• Squelch sensitivity
• Selectivity
• Spurious response
rejection ratio
• Audio output power
• Current drain
Max rated audio/both bands 1.8 A
Max audio/either band
Squelched on both bands
All stated specifications are subject to change without notice or
obligation
POWER
High 50 W
Mid 10 W
Low 5 W
High 35 W
Mid 10 W
Low 5 W
: Double conversion superheterodyne
:
1st 45.05 MHz 2nd 455 kHz
1st 57.65 MHz 2nd 455 kHz
: Less than 0.16 µV
(incl. para watch)
: Less than 0.13 µV
(at threshold)
: More than 15 kHz/–6 dB
Less than 30 kHz/–60 dB
: More than 60 dB
: More than 2.4 W at 10% distortion
with the 8 Ω internal speaker
:
1.5 A
(squelch closed on other band)
1.2 A
19
CURRENT
12.0 A
6.5 A
4.5 A
11.0 A
6.5 A
4.5 A
78
