I Memory clearing

Contents of programmed memories can be cleared (blanked),
if desired.
Push [S.MW] momentarily.
Select the memory channel to be cleared with the tuning
dial.
Push [S.MW] briefly, then a second time for 1 sec.
• 3 beeps sound, then the frequency is cleared.
• "!" flashes continuously.
• Scan edges and call channel cannot be cleared.
Push any switch to stop the flashing.
[EXAMPLE]: Clearing memory channel 20.
1
5
9
Push
S.MW MW
briefly, then push
Push
S.MW MW
momentarily
S.MW MW
again for 1 sec.

MEMORY OPERATION

NOTE:
Be careful—the contents of cleared memories CANNOT
be recalled.
• Memory channel 0 and scan edge channels 1A/1b cannot be
cleared.
Memory clearing may not be performed from the
microphone.
Rotate
Push
6
36
