PAGER AND CODE SQUELCH

PERSONAL CALLS

This display appears when

you are called with your ID

code and the calling station's

ID code is 263.

GROUP CALLS

This display appears when

you are called with the group

code, 123, and 123 has been

programmed into code chan-

nel 5.

ERROR INFORMATION

When the transceiver receives

an incomplete signal, "E" ap-

pears.

SKIP

"E" appears

I Code squelch function

The code squelch function can be used only when an optional

UT-49 is installed.

Code squelch operation provides communication with silent

standby since you only receive calls from stations which know

your ID or group code. To use the code squelch function in

your group, all stations need the code squelch function.

The code squelch function transmits a 3-digit code prior to

voice transmission in order to open the receiving station's

code squelch.

CODE SQUELCH SIMULATION:

000/555

000

111

111/555

No code squelch

function
