D Wireless microphone accessories

HM-90 WIRELESS MICROPHONE

Infrared, full remote control microphone. Wired remote con-

trol is also possible.

EX-1759 INFRARED RECEIVER

Used to receive control signals from the HM-90.

EX-1513 INFRARED SUB RECEIVER

Used with the EX-1759 to increase remote control reliability

and extend the controllable area.

BC-96 MICROPHONE HOLDER

Holds the HM-90 body in a convenient place and supplies

power to the charging circuit of the HM-90. Has a charging

indicator.

CP-13/L CIGARETTE LIGHTER CABLE WITH NOISE FILTER

OPC-288/L DC POWER CABLE

Supply power to the BC-96 for charging the Ni-Cd battery in-

side the HM-90 when the BC-96 cannot be connected to the

EX-1759 directly.

HM-90

BC-96

D Internal units for function enhancements

UT-49 DTMF DECODER UNIT

Provides pager and code squelch functions. Also provides an

external DTMF function for the U.S.A. version only.

UT-104 TONE SQUELCH UNIT

Provides pocket beep, tone squelch and tone scan functions.

D Others

MB-17A MOBILE MOUNTING BRACKET

One-touch bracket. Transceiver body is easily attached and

removed.

IC-PS30 DC POWER SUPPLY

Provides 13.8 V DC and 25 A max. for base station use.

CS-2710 CLONING SOFTWARE + OPC-646 CLONING CABLE

Provides quick and easy programming of items, including

memory channels and set mode contents, for local repeater

frequencies, etc.

MB-17A

OPTIONS

Table of Contents

Show Quick Links

Hide quick links:

Table of Contents

Need help?

Do you have a question about the IC-2710H and is the answer not in the manual?

Questions and answers

Bob

January 20, 2025

Set sub-audible tone to 67 Hz. How do I save it so that it transmits?

1 comments:

Mr. Anderson

February 4, 2025

To save the sub-audible tone setting to 67 Hz on the Icom IC-2710H for transmission, follow these steps:

1. Enter the desired frequency and ensure the radio is in VFO mode.
2. Access the tone setting by pressing the appropriate button (e.g., [SET] or similar).
3. Navigate to the sub-audible tone frequency setting using the tuning dial.
4. Select 67.0 Hz as the tone frequency.
5. Exit the tone setting mode by pressing [ECLR] or the tuning dial.
6. To save the tone setting permanently, overwrite the memory channel with the updated settings.

Note: If you do not overwrite the memory channel, the tone setting will be cleared when switching to memory/call mode.
