REPEATER OPERATION

I Auto repeater

(U.S.A. version only)

The U.S.A. version automatically activates the repeater set-

tings (DUP or DUP– and tone encoder ON/OFF) when the

operating frequency falls within the general repeater output

frequency range and deactivates them when outside of the

range.

D Setting the auto repeater function ON/OFF

➀

Push [POWER] to turn power OFF.

➁

While pushing [

enter initial set mode.

➂

Push [SET L] one or more times until the "rPt" display ap-

pears as shown below.

➃

Rotate the left-hand tuning dial to turn the auto repeater

function ON ("rPt-r1" or "rPt-r2") or OFF ("rPt-oF").

• "rPt-r1" and "rPt-r2" automatically set the duplex setting and du-

plex/tone encoder settings, respectively.

➄

Push [POWER] momentarily to exit initial set mode.

Duplex setting:

Tone encoder:

INITIAL SET MODE

USING

SET L] (left side), turn power ON to

(VOL)

DUP

Automatic ON

Automatic OFF

D Frequency range and offset direction

FREQUENCY RANGE

145.200–145.495 MHz

146.610–146.995 MHz

147.000–147.395 MHz

442.000–444.995 MHz

447.000–449.995 MHz

DUP

Automatic ON

DUPLEX DIRECTION

"DUP–" appears

"DUP" appears

"DUP–" appears
