I DTMF speed

The rate at which DTMF memories send individual DTMF

characters can be set to accommodate operating needs. This

setting does not affect an optional pager or code squelch op-

eration.

Common setting for each band

➀

Push [POWER] to turn power OFF.

➁

While pushing [

SET L] (left side), push [POWER] for

(VOL)

1 sec. to turn power ON and enter initial set mode.

➂

Push [

SET L] or [

(VOL)

(SQL)

play as shown above.

➃

Rotate the main band's tuning dial to select the desired

speed as shown in the table at right.

➄

Push [POWER] momentarily to exit initial set mode.

INITIAL SET MODE

USING

The display shows the fas-

test DTMF speed is selected.

MONI] to select the "dtd" dis-

DTMF MEMORY ENCODER

DISPLAY

INTERVAL

SPEED

dtd-1

100 msec.

5.0 cps

dtd-2

200 msec.

2.5 cps

dtd-3

300 msec.

1.6 cps

dtd-5

500 msec.

1.0 cps

cps=

characters/second
