MAINTENANCE

I Fuse replacement

If the fuse blows or the transceiver stops functioning, ﬁnd the

source of the problem if possible, and replace the damaged

fuse with a new, rated one (FGB 20 A) as shown in the dia-

gram below.

I Partial resetting

If you want to initialize the operating conditions without clear-

ing the memory contents, etc., a partial reset function is avail-

able for the transceiver. The partial reset can be performed

independently for each band.

While pushing either left or right, or both [V/MHz] switches,

turn power ON to partially reset the transceiver.

➧ Initialized settings: VFO frequency, SET mode settings.

➧ Retained settings: Memory channels, call channels, offset

freq. in memory/call, DTMF memory,

pager and code squelch settings, initial

SET mode settings.

I Resetting the transceiver

The function display may occasionally display erroneous in-

formation, (e.g. when first applying power). This may be

caused externally by static electricity or other factors.

If this problem occurs, turn power OFF. After waiting a few

seconds, turn power ON again. If the problem persists, per-

form the following procedure.

Partial resetting is alternatively available. See previous sec-

tion for details.

CAUTION:

Resetting the transceiver CLEARS all

memory information, and initializes all values in the trans-

ceiver.

➀

Push [POWER] to turn power OFF.

➁

While pushing both left and right [S.MW] switches, turn

power ON.

• All LCD segments appear momentarily, the initial display appears

and the transceiver is reset.
