14

OTHER FUNCTIONS

■ Microphone keys

The supplied HM-133's
2] keys memorize the transceiver conditions.
The [UP]/[DN] keys of the standard or an optional microphone
(other than the HM-133)
tion keys on the transceiver's front panel.
D D [F-1]/[F-2] keys on HM-133
The following conditions in the main band or both left and
right bands can be memorized into [F-1] and [F-2] keys, in-
dependently.
Operating frequency, Mode
, Memory name, Repeater setting
channel number)
rection and frequency, tone ON/OFF and frequency)
output power level, Tone/DTCS squelch
quency/code and polarity)
lection
(FM/FM-N/AM/AM-N/DV
, † Call sign/digital code squelch
repeater)
, Set mode settings,* GPS set mode settings,* GPS-
†
code)
A set mode settings,* Display set mode settings,* Sounds
set mode settings,* DV set mode settings,*
*
Only when storing both band's conditions
† Available only when optional UT-123 is installed.
113
[F-1] and [F-
(optional for some versions)
can be assigned functions like the func-
(VFO/Memory/Call channel with
(ON/OFF, fre-
, Tuning step, Operating mode se-
, Call sign
† ) (station and
(ON/OFF and digital
, †
[F-1]/[F-2]
(offset di-
, Transmit
D D [UP]/[DN] keys on a microphones
(other than HM-133)
The following functions are assigned to the [UP]/[DN] keys on
the other microphones
• Default setting
[UP] : channel up; push and hold to start scan, push again
to stop scan.
[DN] : channel down; push and hold to start scan, push
again to stop scan.
See page 100 for assignable function details.
➥ Programming the main band condition
Set the desired contents of each condition in
the main band, then push [F-1]/[F-2] for 1 sec.
• 3 beeps sound.
➥ Recalling the main band condition
Push [F-1]/[F-2] momentarily.
➥ Programming the both bands condition
After setting the desired contents of each
condition in the both bands, push [FUNC]
then push [F-1]/[F-2] for 1 sec.
• 3 beeps sound.
➥ Recalling the both bands condition
Push [FUNC] then [F-1]/[F-2] momentarily.
in set mode.
(HM-154, etc.)
