9. OTHER FUNCTIONS

Microphone keys

D[F-1] and [F-2] on the HM-133V microphone
The following settings can be assigned to the [F-1]
and [F-2] function keys on the HM-133V�
• Operating frequency
• Repeater settings (Offset direction, Offset frequency,
tone ON/OFF, and Repeater Tone frequency)
• Tone/DTCS squelch (ON/OFF, Tone frequency,
DTCS code, and its polarity)
• Transmit output power
• The Settings of the Set mode, Initial Set mode, and
Option Set mode items
Assign the settings:
1� Assign the settings you want to use�
2� Hold down [F-1] or [F-2] for 1 second�
• Three beeps sound and the settings are assigned�
TIP: To assign the settings of the Set mode, Initial
Set mode, and Option Set mode items, push
[FUNC], and then hold down [F-1] or [F-2] for 1
second�
Using the assigned settings:
z Push [F-1] or [F-2]�
• "F1" or "F2" is displayed�
TIP: To recall the settings of the Set mode, Initial Set
mode, and Option Set mode items, push [FUNC],
and then [F-1] or [F-2]�
• "ALLF-1" or "ALLF-2" is displayed�
DThe [UP] and [DN] keys on a
microphone other than the HM-133V
The [UP] and [DN] keys on a microphone other than
the HM-133V have the following functions�
z Push to change the operating frequency, Memory
channel, Set mode setting, and so on�
z Hold down either key for 1 second to start
scanning�
L The scanning direction follows the name of the key
([UP]: Channel up, [DN]: Channel down)�
L Push [MONI ANM PA] to stop or resume the scan�
L Push either key again to cancel the scan�
[F-1] [F-2]
"F1" is displayed�
DIGITAL
MUTE
NAR
MID
LOW
LOCK ANM DUP T-SCAN
S ET MONI LOW TONE M/CALL
When [F-1] is pushed�
DIGITAL
MUTE
NAR
MID
LOW
LOCK ANM DUP T-SCAN
S ET MONI LOW TONE M/CALL
When [FUNC] is pushed,
and then [F-1] is pushed�
Example: HM-154
[DN] [UP]
9-3
"F2" is displayed�
AO
MUTE
NAR
MID
LOW
PRIO SCAN LOCK ANM DUP
V/ MHz S ET MONI LOW
When [F-2] is pushed�
AO
MUTE
NAR
MID
LOW
PRIO SCAN LOCK ANM DUP
V/ MHz S ET MONI LOW
When [FUNC] is pushed,
and then [F-1] is pushed�
DIGITAL AO
T-SCAN PRIO SCAN
TONE M/CALL V/ MHz
DIGITAL AO
T-SCAN PRIO SCAN
TONE M/CALL V/ MHz
