Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone

Firmware Versions Screen

Step 1
Step 2
Step 3
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01
The Firmware Versions screen displays information about the firmware version
running on the phone.
To display the Firmware Version screen, follow these steps:
Procedure
Press the Applications Menu button.
Select Settings. > Status.
Select Firmware Versions.
To exit the Firmware Version screen, press the Exit softkey.
Table 7-5 provides a list of Firmware Version items and a description of each.
Table 7-5 Firmware Version Information
Item
Load File
App Load ID
JVM Load ID
OS Load ID
Boot Load ID
DSP Load ID
Description
Load file running on the phone
Identifies the JAR file running on the phone
Identifies the Java Virtual Machine (JVM) running
on the phone
Identifies the operating system running on the phone
Identifies the factory-installed load running on the
phone
Identifies the DSP load file running on the phone.
Status Menu
7-15
