Physical and Operating Environment Specifications

Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01

Technical Specifications

The following sections describe the technical specifications for the
Cisco Unified IP Phones 7906G and 7911G.
Physical and Operating Environment Specifications, page D-1
•
Cable Specifications, page D-2
•
Network and Access Port Pinouts, page D-3
•
Table D-1 shows the physical and operating environment specifications for the
Cisco Unified IP Phone.
Table D-1 Physical and Operating Specifications
Specification
Operating temperature 32° to 104°F (0° to 40°C)
Operating relative
humidity
Storage temperature
Height
Width
Depth
Weight
A P P E N D I X
Value or Range
10% to 95% (non-condensing)
14° to 140°F (–10° to 60°C)
6.5 in. (20.3 cm)
7 in. (17.67 cm)
6 in. (15.2 cm)
1.9 lb (0.9 kg)
D
D-1
