Network Configuration Menu
Table 4-2 Network Configuration Menu Options (continued)
Option Description
PC Port Speed and duplex of the access port (labeled
Configuration 10/100 PC). Valid values:
(applies to 7911G
•
only)
•
•
•
•
If the phone is connected to a switch,
configure the port on the switch to the same
speed/duplex as the phone, or configure both
to auto-negotiate.
If you change the setting of this option, you
must change the SW Port Configuration
option to the same setting.
PC VLAN Allows the phone to work better with
(applies to 7911G non-Cisco switches. Strips the 802.1P/Q tags
only) from the packets going to a PC from the
access port on the phone. The Admin. VLAN
ID must be set before you can change this
option.
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
4-14
Auto Negotiate
10 Half—10-BaseT/half duplex
10 Full—10-BaseT/full duplex
100 Half—100-BaseT/half duplex
100 Full—100-BaseT/full duplex
Related Topics
Displaying a Configuration Menu, page 4-2
•
Unlocking and Locking Options, page 4-4
•
Editing the Values of an Option Setting, page 4-5
•
Overview of Options Configurable from a Phone, page 4-6
•
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
To Change
Unlock network configuration
1.
options.
Scroll to the PC Port
2.
Configuration option and then
press the Edit softkey.
Scroll to the setting that you
3.
want and then press the Select
softkey.
Press the Save softkey.
4.
Unlock network configuration
1.
options.
Make sure the Admin. VLAN
2.
ID option is set.
Scroll to the PC VLAN
3.
option, press the Edit softkey,
and then enter a new PC
VLAN setting.
Press the Validate softkey and
4.
then press the Save softkey.
OL11954-01
