Overview of Options Configurable from a Phone

Overview of Options Configurable from a Phone
Note
Table 4-1 Network Configuration Menu Settings
Category
DHCP settings
IP settings
TFTP settings
VLAN settings
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
4-6
The settings that you can change on a phone fall into several categories, as shown
in Table 4-1. For a detailed explanation of each setting and instructions for
changing them, see the
There are several options on the Network Configuration menu and on the Device
Configuration Menu that are for display only or that you can configure from
Cisco Unified Communications Manager. These options are also described in the
"Network Configuration Menu" section on page 4-7
Configuration Menu" section on page
Description
Dynamic Host Configuration Protocol (DHCP)
automatically assigns IP address to devices
when you connect them to the network.
Cisco Unified IP Phones enable DHCP by
default.
If you do not use DHCP in your network, you
can make IP settings manually.
If you do not use DHCP to direct the phone to
a TFTP server, you must manually assign a
TFTP server. You can also assign an alternative
TFTP server to use instead of the one assigned
by DHCP.
Allow you to change the administrative VLAN
used by the phone.
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
"Network Configuration Menu" section on page
4-15.
and the or the "Device
Network Configuration Menu
Option
DHCP Enabled
DHCP Address Released
Domain Name
IP Address
Subnet Mask
Default Router 1-5
DNS Server 1-5
TFTP Server 1
Alternate TFTP
TFTP Server 2
Admin. VLAN ID
PC VLAN (applies to 7911G
only)
OL11954-01
4-7.
