Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Table 4-21 802.1X Authentication Real-Time Status
Option
802.1X
Authentication Status
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01
Description
Real-time progress of the 802.1X
authentication status. Displays one
of the following states:
Disabled—802.1X is disabled
•
and transaction was not
attempted
Disconnected—Physical link
•
is down or disconnected
• Connecting—Trying to
discover or acquire the
authenticator
Acquired—Authenticator
•
acquired, awaiting
authentication to begin
• Authenticating—Authentication
in progress
Authenticated—Authentication
•
successful or implicit
authentication due to timeouts
Held—Authentication failed,
•
waiting before next attempt
(approximately 60 seconds)
Security Configuration Menu
To Change
Display only—Cannot configure.
4-45
