Model Information Screen

Model Information Screen
Step 1
Step 2
Table 7-1 Model Information
Option Description
Model Number Model number of the phone
MAC Address MAC address of the phone
Load File Identifier of the factory-installed load
running on the phone
Boot Load ID Identifier of the factory-installed load
running on the phone
Serial Number Serial number of the phone
CTL Displays the MD5 hash of the
certificate trust list (CTL) file that is
installed in the phone. If no CTL file is
installed on the phone, this field
displays No. (If security is configured
for the phone, the CTL file installs
automatically when the phone reboots
or resets. For more information about
this file, refer to
Cisco Unified Communications
Manager Security Guide.)
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
7-2
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
The Model Information screen displays specific information about the IP phone.
To display the Model Information screen, follow these steps:
Procedure
Press the Applications Menu button.
Select Settings > Model Information.
Table 7-1 provides a list of Model Information items and a description of each.
To Change
Display only—Cannot configure
Display only—Cannot configure
Display only—Cannot configure
Display only—Cannot configure
Display only—Cannot configure
For more information about this file, refer
to Cisco Unified Communications
Manager Security Guide.
