Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Table 4-14 Security Configuration Menu Options (continued)
Option Description
Voice VLAN Indicates whether the phone allows a
Enabled (applies device attached to the access port to
to 7911G only) access the Voice VLAN. Setting this
option to No (disabled) prevents the
attached PC from sending and
receiving data on the Voice VLAN.
This setting also prevents the PC from
receiving data sent and received by the
phone. Set this setting to Yes (enabled)
if an application that requires
monitoring of the phone's traffic is
running on the PC. These applications
include monitoring and recording
applications and network monitoring
software.
Web Access Indicates whether web access is
Enabled enabled (Yes) or disabled (No) for the
phone.
Security Mode Displays the security mode that is set
for the phone.
Logging Display Used by Cisco Technical Assistance
Center (TAC) for troubleshooting.
The Cisco Unified IP Phone 7911G can
be configured for Enabled/Disabled/PC
Controlled.
The Cisco Unified IP Phone 7906G
supports only Enabled/Disabled (no PC
Controlled).
QoS Configuration Menu
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01
The QoS Configuration menu displays information that relates to quality of
service (QoS) for the phone.
options.
To Change
From Cisco Unified Communications
Manager Administration, choose Device
> Phone > Phone Configuration.
From Cisco Unified Communications
Manager Administration, choose Device
> Phone > Phone Configuration.
Use Cisco Unified Communications
Manager Administration to modify.
—
Table 4-15 describes the QoS Configuration menu
Device Configuration Menu
4-33
