Chapter 3 Setting Up the Cisco Unified IP Phone
Figure 3-3 Cisco Unified IP Phone Model 7906G Cable Connections
3
10/100 SW
4
5
1
Network port (10/100 SW)
2 Handset port
3
DC Adapter port (DC48V)
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01
1
Installing the Cisco Unified IP Phone
2
4
AC-to-DC power supply
5 AC power cord
