Cisco 7911G Basic User's Manual

C IP P
ISCO HONE
Displays features such as the time, date,
1 LCD screen your phone number, caller ID, call status,
and soft key tabs.
Cisco IP
Indicates the Cisco IP Phone Series to
2 Phone
which your phone belongs.
series type
Enable you to engage any of the
functions displayed on the corresponding
LCD screen tabs. Soft keys point to
feature options displayed along the
3 Soft keys
bottom of your LCD screen. Soft key
functions change depending on the status
of your phone (for example, if the phone
is active or idle).
Navigation
Enables you to scroll through text and
button
select features displayed on the LCD
4
screen. Also provides access to speed dial
numbers when there are no text or
features to scroll through.
Menu
Displays a menu that provides access to a
button
5 voice messaging system, phone logs and
directories, settings, and services.
Appleton Chicago Cincinnati
{Information taken from "Cisco IP Phone Guide 7905G/7912G for Cisco Call Manager 4.1.3" -
Cisco IP Phone 7911G Basic User Guide
7911G
(R : 9/12/08)
EVISED
Cleveland Detroit
ccmigration_09186a00804134a4.pdf}

Hold button

6
7 Keypad
Volume
button
8
9 Handset
10 Footstand
U
SING THE
Your Cisco IP Phone has two feature buttons:
Menu Button
Menu button Displays a menu that provides access to a voice
messaging system, access to various directories (including call
history and speed dials), access to settings (including contrast,
ring type, configuration, and status), and access to services (if
set up by your system administrator). For more information,
see the "Using the Cisco IP Phone Menus"
Hold Button
Hold button puts an active call on hold or resumes a call on
hold. See the "Putting a Call on Hold" section
information.
Grand Rapids Indianapolis
Wausau
Places the active call on hold, resumes a
call on hold, and switches between an
active call and an incoming call or an
active call and a call on hold.
Works exactly like the keypad on a
traditional telephone.
Increases or decreases volume for the
handset and speaker. Also controls the
ringer volume (if on-hook).
Functions like a traditional handset. The
light strip at the top of the handset blinks
when the phone rings and remains lit to
indicate a new voice messages
(depending on your message system).
Allows the phone to stand at a
convenient angle on a desk or table.
M H B
ENU AND OLD
section.
