Clearance Requirements

A minimum clearance of at least 6 inches (150 mm) is suggested on the top and both
sides of the product for service.
See Appendix B: Dimensions

Electrical Requirements

The product models have the following electrical requirements.
Catalog Number
3x239xx02
3x239xx22
3x239xx-12, 32, 42, 52, 62, 72
3x249xx02
3x249xx22
3x249xx-12, 32, 42, 52, 62, 72
3x259xx02
3x259xx22
3x259xx-12, 32, 42, 52, 62, 72
3x269xx02
3x269xx22
3x269xx-12, 32, 42, 52, 62, 72
1 Electrical Requirements, 'V' = VAC (Voltage with alternating current), 'A' = Amperes
A dedicated outlet with an appropriate circuit breaker should be located as close as
possible to the product, but no greater than 10 feet (3 m). Consult your local electrical
codes for properly rated circuit breakers. For safe operation the dedicated outlet must
provide a protective earthing ground connection to the product.
On 100V and 115V models, both internal electrical outlets are protected by a ground
fault interrupter circuit (GFIC). Labconco does NOT recommend connecting the
product's power cord into a GFIC outlet. GFIC outlets can nuisance trip, resulting in
complete removal of power to the product. Such a scenario would result in complete
loss of product and/or personnel protection.

Service Line Requirements

All utility service lines should be ¼ inch O.D., brass, copper, or stainless steel, and
equipped with an easily accessible shut-off valve. The service valves are rated for
operation at 40 PSI (275 kPa). If the service line pressure exceeds this, it must be
equipped with a pressure regulator to reduce the line pressure.
for overall product dimensions.
Typical Operating
Current (Amps)
3 A
3 A
1.5 A
3 A
3 A
1.5 A
5 A
5 A
2.5 A
6.5 A
6.5 A
3.3 A
11
Electrical Circuit Requirements
115 V, 60 Hz, 12 A
100 V, 50/60 Hz, 12 A
230 V, 50/60 Hz, 6 A
115 V, 60 Hz, 12 A
100 V, 50/60 Hz, 12 A
230 V, 50/60 Hz, 6 A
115 V, 60 Hz, 16 A
100 V, 50/60 Hz, 16 A
230 V, 50/60 Hz, 8 A
115 V, 60 Hz, 16 A
100 V, 50/60 Hz, 16 A
230 V, 50/60 Hz, 8 A
1
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
