7: Using Your Cell Logic Type A2
This section details the functional features and proper techniques for safely and
efficiently using the Cell Logic Type A2 biosafety cabinet.
Feature Overview
Figure 7-1 illustrates key features and components of the product.
Exhaust Cover
(Optional) UV Lamp
Glass Sash
Pure-Vu Seal
Sash Postion Label
(Optional) Vacu-Pass (LH)
Reset Switch and Breakers
Front Grille
66
Figure 7-1
(Optional) IV Bar
Attachment Point
Serial Tag
GFCI Outlet (RH)
Touch-Screen Display
Keypad
Mag-Zone Area
(Optional) Service Fixture
(Optional) Vacu-Pass (RH)
USB Port
Dished Work Surface
