Front Grille Removal
Before beginning, the dished work surface must be securely lifted or removed, as
described previously. Reference Figure 7-1 for parts identification.
1. If not already on, turn the cabinet blower on.
2. Grasp the front grille with two hands, one on the inside edge and one on the
outside edge. Pull the front grille up, while also rotating the top slightly inward.
Note: It may be difficult to raise the front grille at first. If so, move to one end of the front
grille, and follow step #2 while also rotating the grille up on that end. Once one end has
raised slightly, then move back to the middle and continue to lift it up.
If removing the front grille from the cabinet, the front grille must be thoroughly
decontaminated before removing it from the cabinet.
Front Panel Removal
Removal of the front panel is only necessary to change the LED lamps.
Tools Required:
• #2 Phillips Screwdriver
It is recommended to utilize at least two (2) persons to remove the front panel,
particularly for a 6-ft model. The front panel is heavy. Take care to use safe lifting
practices, and to set the panel where it cannot fall over while uninstalled from the
cabinet.
Before removing the dress panel, remove all electrical power to the cabinet by
disconnecting the power cord from the cabinet.
1. Locate and remove the two Phillips screws that secure
the front panel as shown in Figure 8-4. They are located
on the bottom corners of the front dress panel.
2. Swing the bottom of the dress panel out to clear the LED
lamps and then lift the front dress panel straight up and
away from the cabinet.
79
Figure 8-4
