Step 2 – Installation on an Existing Work Surface
Move the cabinet, attached to its pallet, by using a floor jack, or a furniture dolly
underneath the unit. DO NOT move the cabinet by tilting it onto a hand truck.
When lifting the cabinet DO NOT lift the cabinet in the middle front area of the hull.
Lifting here may bend or distort the bottom of the cabinet, causing damage to the unit.
Note: The cabinet is very top heavy. Use caution when lifting or moving it.
When installing the cabinet onto an existing work surface or benchtop, ensure that the
structure can safely support the combined weight of the cabinet and any related
equipment. The work surface should be at least as wide as the cabinet and 31 inches
(787 mm) deep to properly support the unit. A hole or notch may be cut in the
supporting surface in the right front corner to accommodate the optional drain valve.
Step 2 – Installation on a Labconco Base Stand
Move the cabinet, attached to its pallet, by using a floor jack, or a furniture dolly
underneath the unit. DO NOT move the cabinet by tilting it onto a hand truck.
When lifting the cabinet DO NOT lift the cabinet in the middle front area of the hull.
Lifting here may bend or distort the bottom of the cabinet, causing damage to the unit.
Note: The cabinet is very top heavy. Use caution when lifting or moving it.
Labconco offers accessory base stands in a variety of configurations to suit your
particular needs. If assembly of the base stand is required, the assembly instructions
are packaged with the base stand.
Using a mechanical lift, raise the cabinet.
Before setting the cabinet onto the stand, using the four attachment bolts supplied with
the stand, align the mounting tab holes on the cabinet with the four holes on the stand's
top rail. Drop each bolt through the mounting tab hole and into each hole on the stand's
top rail. Carefully lower the cabinet onto the stand. See Figure 4-2.
After the cabinet is in place, remove each attachment bolt, and flip it over to install it up
through the stand's top rail, and add the associated washers and nut. Tighten each bolt.
