2. Hinge the cover up from the front using the lift slot.
3. If full removal is not needed, Skip to step 5. To remove the exhaust cover, pull
the slightly lifted exhaust cover forward, until the hinges (reference Figure 8-10)
of the cover are free from the cabinet.
4. Once free, carefully pull away and lower from the cabinet. Store safely.
5. If leaving the cover installed, the exhaust cover can be secured in the lifted
position by using the exhaust cover prop. Rotate the prop up and against the
exhaust cover. Insert the end of the prop into the exhaust cover perforations to
keep the cover lifted to height required for servicing. Reference Figure 8-10.
6. Carefully lower the exhaust cover onto the prop and release when stable. Do not
release the exhaust cover if the prop is not fully in place against the cover.
Towel Catch Removal
To remove the Towel Catch and Pre-Filters for periodic cleaning/replacement, follow
these steps.
The Towel Catch, Pre-Filters and the work area of the cabinet must be thoroughly
decontaminated before removing the Towel Catch or Pre-Filters.
1. Remove the work surface as described above. The work surface MUST be removed
before the towel catch will be freed for removal.
83
Figure 8-10
