Daylight Savings (ON/OFF)
Savings Time (DST).
Selecting the Units of Measure
Touch [Units]. This screen allows the user to change the units of measure for various
sensors. Touch the desired drop-down field, and make selection:
•
– Select the desired units of measure: inches or centimeters
Length
•
– Select the desired units of measure: fpm or m/s
Velocity
Once the selection is made, touch [OK].
Activating the Security Lock
Touch [Security]. Security codes can be set to limit
access or prevent modification to certain areas of the
cabinet control system. Supports two PINs (User and
Admin), that can be set in this menu. Select the areas of
the cabinet that are desired to be password protected. If
User is selected, Admin is automatically selected as well.
If 'System' is selected to require a security code, the
applicable PIN is needed upon wake from sleep screen
and the Display Screen Timeout cannot be 'Never'. After
any features are selected to be password protected, the
Security Enabled toggle must be set to enable.
The Default PIN is '1 2 3
Admin. The PIN can be changed by pressing
PIN] or [SET ADMIN PIN]
There is no PIN recovery function. If the PIN is forgotten,
you cannot access the touchscreen controls.
Setting the Data Acquisition Rate
Logs]. This screen provides settings for the data log functionality.
Touch [Data
•
Data Acquisition Rate
& 10min.
•
Log File Deletion
are 1, 3, 6, or
– Enabled/disabled for areas observing Daylight
4' for User, and
as shown in Figure 6-7.
– The available rates are 10s, 30s, 1min, 2min, 3min,
– Saved data logs delete after this time. Deletion rate options
12 months (1 year) with 1 year being the default value.
'1 9 2 5' for
[SET USER
52
Figure 6-7
5min
