9: Accessories

This section details the available field-installable accessories and approved
modifications for your Cell Logic Type A2 biosafety cabinet.

IV Bar

The IV Bar can be field installed on any size Cell Logic A2 biosafety cabinet. The bar
allows for easy hanging of IV bags used inside the biosafety cabinet. Catalog numbers
are listed in Table 9-1 below.

Ventus II Canopy

Adds only 1.25" to the overall height of the cabinet. Powder-coated steel. Outlet is 10"
(25.4 cm) ID. Exhaust connection is required. The catalog number is listed in Table 9-2.
The optional air-tight damper, catalog number 3776800, is recommended (as shown in
Figure 2-6).
Cabinet Catalog
Width (Feet) Number
3'
3288900
4'
3288901
5'
3288902
6'
3288903
Cabinet Catalog
Width (feet) Number
3 3889210
4 3889211
5 3889212
6 3889213
87
Table 9-1
Table 9-2
