6. Remove the 14 screws (#6-32 x 0.25") that retain the Pure-Vu Seal.

7. Either reinstall one of the pre-cut accessory Pure-Vu Seals from Section 9 or

punch the holes in the blank seal supplied and then re-install the seal. For your

convenience, see Appendix E for installation of pleated Pure-Vu XL Seals used

with stereoscopes requiring frequent eyepiece height adjustment of +/- 2.0" (51

mm).

8. After the seal is re-installed, then move the microscope forward to carefully

stretch the Pure-Vu Seal over both of the microscope eyepiece bases.

9. Finally, re-install the microscope eyepieces.

10. The Pure-Vu Seal should now provide an optimum seal for safe airflow and

ergonomic visibility.

Pure-Vu Seal

Outer Aerodynamic

Scope Collar

Mounting Screws

Figure 4-9
