CLI – This example also displays the address table entries for port 1.
Console#show mac-address-table interface ethernet 1/1
Interface Mac Address
--------- ----------------- ---- -----------------
Eth 1/ 1 00-12-CF-48-82-93
Eth 1/ 1 00-12-CF-94-34-DE
Console#

Changing the Aging Time

You can set the aging time for entries in the dynamic address table.
Command Attributes
• Aging Status – Enables/disables the function.
• Aging Time – The time after which a learned entry is discarded.
(Range: 10-630 seconds; Default: 300 seconds)
Web – Click Address Table, Address Aging. Specify the new aging time, click Apply.
CLI – This example sets the aging time to 300 seconds.
Console(config)#mac-address-table aging-time 300
Console(config)#
Vlan Type
1 Delete-on-reset
2 Learned

Figure 3-88 Setting the Address Aging Time
