Ethernet traffic must not be mapped to another VLAN or you will lose
administrative network connectivity to the switch. If lost in this manner, network
access can be regained by removing the offending Protocol VLAN rule via the
console. Alternately, the switch can be power-cycled, however all unsaved
configuration changes will be lost.

protocol-vlan protocol-group (Configuring Groups)

This command creates a protocol group, or to add specific protocols to a group. Use
the no form to remove a protocol group.
Syntax
protocol-vlan protocol-group group-id [{add | remove} frame-type frame
protocol-type protocol]
no protocol-vlan protocol-group group-id
• group-id - Group identifier of this protocol group. (Range: 1-2147483647)
• frame26 - Frame type used by this protocol. (Options: ethernet, rfc_1042,
llc_other)
• protocol - Protocol type. The only option for the llc_other frame type is
ipx_raw. The options for all other frames types include: ip, arp, rarp, and
user-defined (0801-FFFF hexadecimal).
Default Setting
No protocol groups are configured.
Command Mode
Global Configuration
Example
The following creates protocol group 1, and specifies Ethernet frames with IP and
ARP protocol types:
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type ip
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type arp
Console(config)#

protocol-vlan protocol-group (Configuring Interfaces)

This command maps a protocol group to a VLAN for the current interface. Use the
no form to remove the protocol mapping for this interface.
Syntax
protocol-vlan protocol-group group-id vlan vlan-id
no protocol-vlan protocol-group group-id vlan
• group-id - Group identifier of this protocol group. (Range: 1-2147483647)
• vlan-id - VLAN to which matching protocol traffic is forwarded.
(Range: 1-4094)
26. SNAP frame types are not supported by this switch due to hardware limitations.
4
VLAN Commands
4-241
