Figure 3-92 Configuring Spanning Tree Per Port - SMC Networks 8126PL2-F - annexe 1 Management Manual

Web – Click Spanning Tree, STA, Port Configuration or Trunk Configuration. Modify
the required attributes, then click Apply.
CLI – This example sets STA attributes for port 7.
Console(config)#interface ethernet 1/7
Console(config-if)#spanning-tree port-priority 0
Console(config-if)#spanning-tree cost 50
Console(config-if)#spanning-tree link-type auto
Console(config-if)#no spanning-tree edge-port
Console(config-if)#

Figure 3-92 Configuring Spanning Tree per Port

Spanning Tree Algorithm Configuration
3
4-155
4-208
4-206
4-210
4-208
3-157
