3
Configuring the Switch
Web – Click System, System Information. Specify the system name, location, and
contact information for the system administrator, then click Apply. (This page also
includes a Telnet button that allows access to the Command Line Interface via Telnet.)
CLI – Specify the hostname, location and contact information.
Console(config)#hostname R&D 5
Console(config)#snmp-server location WC 9
Console(config)#snmp-server contact Ted
Console(config)#exit
Console#show system
System Description: SMC TigerSwitch 10/100/1000 PoE SMC8126PL2-F
System OID String: 1.3.6.1.4.1.202.20.74
System information
System Up Time:
System Name:
System Location:
System Contact:
MAC Address (Unit1):
Web Server:
Web Server Port:
Web Secure Server:
Web Secure Server Port:
Telnet Server:
Telnet Server Port:
Jumbo Frame:
POST result
DUMMY Test 1 ................. PASS
UART Loopback Test ........... PASS
DRAM Test .................... PASS
Timer Test ................... PASS
PCI Device 1 Test ............ PASS
Done All Pass.
Console#
3-12

Figure 3-3 System Information

0 days, 2 hours, 18 minutes, and 36.38 seconds
[NONE]
[NONE]
[NONE]
00-D0-CB-6A-23-F3
Enabled
80
Enabled
443
Enable
23
Disabled
4-16
4-64
4-64
4-21
