Web – Click Port, Mirror Port Configuration. Specify the source port, the traffic type
to be mirrored, and the monitor port, then click Add.
CLI – Use the interface command to select the monitor port, then use the port
monitor command to specify the source port and traffic type.
Console(config)#interface ethernet 1/10
Console(config-if)#port monitor ethernet 1/13 tx
Console(config-if)#

Configuring Rate Limits

This function allows the network manager to control the maximum rate for traffic
received or transmitted on an interface. Rate limiting is configured on interfaces at
the edge of a network to limit traffic into or out of the switch. Packets that exceed the
acceptable amount of traffic are dropped.
Rate limiting can be applied to individual ports or trunks. When an interface is
configured with this feature, the traffic rate will be monitored by the hardware to
verify conformity. Non-conforming traffic is dropped, conforming traffic is forwarded
without any changes.

Rate Limit Configuration

Use the rate limit configuration pages to apply rate limiting.
Command Usage
Input and output rate limits can be enabled or disabled for individual interfaces.
Command Attributes
• Port/Trunk – Displays the port/trunk number.
• Rate Limit Status – Enables or disables the rate limit. (Default: Disabled)
• Rate Limit – Sets the rate limit level. (Range: 1 to 1000 Mbps)

Figure 3-79 Mirror Port Configuration
