Configuring the Switch

Displaying MVR Interface Status

You can display information about the interfaces attached to the MVR VLAN.
Field Attributes
• Type – Shows the MVR port type.
• Oper Status – Shows the link status.
• MVR Status – Shows the MVR status. MVR status for source ports is "ACTIVE" if
MVR is globally enabled on the switch. MVR status for receiver ports is "ACTIVE"
only if there are subscribers receiving multicast traffic from one of the MVR groups,
or a multicast group has been statically assigned to an interface.
• Immediate Leave – Shows if immediate leave is enabled or disabled.
• Trunk Member
Web – Click MVR, Port or Trunk Information.
CLI – This example shows information about interfaces attached to the MVR VLAN.
Console#show mvr interface
Port Type
------- -------- ------------- ---------------
eth1/1 SOURCE
eth1/2 RECEIVER ACTIVE/UP
Console#
17. Port Information only.
3-226
17
– Shows if port is a trunk member.

Figure 3-131 MVR Port Information

Status Immediate Leave
ACTIVE/UP Disable
Disable
